Outdoor Rental Transparent LED Display
GLK1000TOF series transparent LED screen, slim, strong, seamless assembly, high light transmittance, up to 70%.
Easy installation, support front and rear service. IP65 waterproof and dustproof, 1000x500mm standard size.
70% High Transparency
70% transparency, greatly reduced wind resistance, and better cooling effect, without affecting the outdoor vision
High Precision Curve Lock
A precision Curve Lock design is adopted to solve the problem that the old curved lock was difficult to use before.
Rotational control is more accurate, easy to use, and quickly adjusts curve degree.
Super Wide Viewing Angle
The viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle gives you the largest screen viewing area. It offers you clear and natural images in all directions.
| Pixel Pitch (mm) | P3.91-7.82 | P5.2-10.4 | P10.4 | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Outdoor 1000x500mm Rental Transparent LED Display Parameter
|
|||||||||||||||||||
| Pixel Configuration | GLK1000TOR P3.91-7.82 | GLK1000TOR P5.2-10.4 | GLK1000TOR P10.4 | ||||||||||||||||
| Pixel Configuration | SMD1921 | SMD1921 | SMD2727 | ||||||||||||||||
| Density (Pixels/㎡) | 32,768 | 18432 | 9216 | ||||||||||||||||
| Cabinet Resolution (Pixel) | 256×64 | 192×48 | 96×48 | ||||||||||||||||
| Module Resolution (Pixel) | 128×32 | 96×24 | 48×24 | ||||||||||||||||
| Module Size (mm) | 500×250 | 500×250 | 500×250 | ||||||||||||||||
| Driving Mode (Duty) | 1/8 | 1/4 | 1/2 | ||||||||||||||||
| Cabinet Size (mm) | 1000×500 | 1000×500 | 1000×500 | ||||||||||||||||
| Cabinet Weight (KG) | 7.5 | 7.5 | 7.5 | ||||||||||||||||
| Brightness (CD/㎡) | 4500 | 4500 | 4500 | ||||||||||||||||
| Transparency | 53 | 58 | 70 | ||||||||||||||||
| Viewing Angle (°) | 140 | 140 | 140 | ||||||||||||||||
| Gray Grade (Bits) | 14 | 14 | 14 | ||||||||||||||||
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | ||||||||||||||||
| Max. Power Consumption (W/㎡) | 800 | 800 | 800 | ||||||||||||||||
| Avg. Power Consumption (W/㎡) | 260 | 260 | 260 | ||||||||||||||||
| Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 | ||||||||||||||||
| Refresh Frequency (Hz) | ≥3,840 | ≥3,840 | ≥3,840 | ||||||||||||||||
| Working Temperature (ºC) | -20～+60 | -20～+60 | -20～+60 | ||||||||||||||||
| Lifetime (Hours) | 100,000 | 100,000 | 100,000 | ||||||||||||||||
