Outdoor Fixed Installation Transparent LED Display
GLK1000TOF series outdoor transparent LED screen, light&slim, high transparency, up to 70%.
The LED lamp & PCB are fully sealed by silicon, anti-dust and anti-collision, IP65, adapt to harsh weather.
Easy installation, support front&rear service.
Contact Us For More Information
70% High Transparency
70% transparency, greatly reduced wind resistance, and better cooling effect, without affecting the outdoor vision
Contact Us For More Information
Easy to Install
Stacking, hanging, and fixed installations are supported.
Contact Us For More Information
Super Wide Viewing Angle
The viewing angle is up to 140° vertical and horizontal, providing a wide viewing angle.
Ultra-wide viewing angle gives you the largest screen viewing area. It offers you clear and natural images in all directions.
Contact Us For More Information
Outdoor GLK1000TOF 1000x500mm Fixed Installation Transparent LED Display Parameter
| Pixel Pitch (mm) | P3.91-7.82 | P5.2-10.4 | P10.4 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|||||||||||||||
| Model | GLK1000TOF-P3.91 | GLK1000TOF-P5.2 | GLK1000TOF-P10.4 | ||||||||||||
| Pixel Configuration | SMD1921 | SMD1921 | SMD2727 | ||||||||||||
| Density (Pixels/㎡) | 32,768 | 18432 | 9216 | ||||||||||||
| Cabinet Resolution (Pixel) | 256×64 | 192×48 | 96×48 | ||||||||||||
| Module Resolution (Pixel) | 128×32 | 96×24 | 48×24 | ||||||||||||
| Module Size (mm) | 500×250 | 500×250 | 500×250 | ||||||||||||
| Driving Mode (Duty) | 1/8 | 1/4 | 1/2 | ||||||||||||
| Cabinet Size (mm) | 1000×500 | 1000×500 | 1000×500 | ||||||||||||
| Cabinet Weight (KG) | 7.5 | 7.5 | 7.5 | ||||||||||||
| Brightness (CD/㎡) | 4500 | 4500 | 4500 | ||||||||||||
| Transparency | 53 | 58 | 70 | ||||||||||||
| Viewing Angle (°) | 140 | 140 | 140 | ||||||||||||
| Gray Grade (Bits) | 14 | 14 | 14 | ||||||||||||
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz | ||||||||||||
| Max. Power Consumption (W/㎡) | 800 | 800 | 800 | ||||||||||||
| Avg. Power Consumption (W/㎡) | 260 | 260 | 260 | ||||||||||||
| Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 | ||||||||||||
| Refresh Frequency (Hz) | 3,840 | 3,840 | 3,840 | ||||||||||||
| Working Temperature (ºC) | -20～+60 | -20～+60 | -20～+60 | ||||||||||||
| Lifetime (Hours) | 100,000 | 100,000 | 100,000 | ||||||||||||
