GLK1000TiR Series Indoor Rental Transparent LED Display
GLK1000TiR series transparent rental LED display for rental application with quick set-up, super high permeability,
ultra-thin Ultra-light structure design, high precision,modularized design, more than 70% transparency, easy installation and disassamble.
Contact Us For More Information
70% High Transparency
70% transparency, greatly reduced wind resistance, and better cooling effect, without affecting the indoor vision
Contact Us For More Information
Easy to Install
Stacking, hanging, and fixed installations are supported.
Contact Us For More Information
Indoor 1000x500mm Rental Transparent LED Display Parameter
| Pixel Pitch (mm) | P3.91-7.82 | P3.91-7.82 | P7.81 |
|---|---|---|---|
| Pixel Configuration | GLK1000TiR-P3.91-8S | GLK1000TiR-P3.91-16S | GLK000TiR-P7.81 |
| Pixel Configuration | SMD1921 | SMD1921 | SMD1921 |
| Density (Pixels/㎡) | 32,768 | 32,768 | 16,384 |
| Module Resolution (Pixel) | 128×16 | 128×16 | 64×16 |
| Module Size (mm) | 500×125 | 500×125 | 500×125 |
| Driving Mode (Duty) | 1/8 | 1/16 | 1/4 |
| Cabinet Size (mm) | 1000×500 | 1000×500 | 1000×500 |
| Cabinet Weight (KG) | 7.5 | 7.5 | 7.5 |
| Brightness (CD/㎡) | 4500 | 2500 | 4500 |
| Transparency | 53 | 53 | 58 |
| Viewing Angle (°) | 140 | 140 | 140 |
| Gray Grade (Bits) | 14 | 14 | 14 |
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
| Max. Power Consumption (W/㎡) | 800 | 800 | 800 |
| Avg. Power Consumption (W/㎡) | 220 | 220 | 220 |
| Frame Frequency (Hz) | ≥60 | ≥60 | ≥60 |
| Refresh Frequency (Hz) | 3840 | 3840 | 3840 |
| Working Temperature (ºC) | -20～+60 | -20～+60 | -20～+60 |
| Lifetime (Hours) | 100,000 | 100,000 | 100,000 |
| Protecting Grade | IP33 | IP33 | IP33 |
