GLK1000Tip Indoor Transparent Poster LED Display
Goldluck LED transparent screen has the characteristics of high transparency, ultra-lightweight,
intelligent control, high refresh rate, energy saving, and so on.
It is used in architectural glazing, shops, bars, shopping malls, etc.
Contact Us For More Information
Easy to Install
Three 1000x500mm cabinets can quickly combine 1000x1500mm LED displays.
Stacking, hanging, and fixed installations are supported.
Contact Us For More Information
No Need Steel Structure
A thinner and lighter display body. can be easily installed to the original glass curtain window wall without any additional steel structure.
Contact Us For More Information
Indoor 1000x500mm Transparent Poster LED Display Parameter
| Pixel Pitch (mm) | P3.91-P7.82 (1500) | P3.91-P7.82 (2000) |
|---|---|---|
| Model | GLK1000TiP-P3.91(1500) | GLK1000TiP-P3.91(2000) |
| Pixel Configuration | SMD1921 | SMD1921 |
| Density (Pixels/㎡) | 32,768 | 32,768 |
| Module Resolution (Pixel) | 128×16 | 128×16 |
| Module Size (mm) | 500×125 | 500×125 |
| Driving Mode (Duty) | 1/8 | 1/8 |
| Cabinet Size (mm) | 1000×1500 | 1000×2000 |
| Cabinet Weight (KG) | 14.5 | 18 |
| Brightness (CD/㎡) | ≥5,000 | ≥5,000 |
| Transparency | 70 | 70 |
| Viewing Angle (°) | 140 | 140 |
| Gray Grade (Bits) | 14 | 14 |
| Operation Power | AC100-240V 50-60Hz | AC100-240V 50-60Hz |
| Max. Power Consumption (W/㎡) | 800 | 800 |
| Avg. Power Consumption (W/㎡) | 220 | 220 |
| Frame Frequency (Hz) | ≥60 | ≥60 |
| Refresh Frequency (Hz) | ≥3,840 | ≥3,840 |
| Working Temperature (℃) | -20～+60 | -20～+60 |
| Lifetime (Hours) | 100,000 | 100,000 |
| Protection Grade | IP31 | IP31 |
